Drum Screen Machine

Our drum screen machine is usually used after H.C. Pulper or impurity separator, to screen out all kinds of impurities such as plastics, rubber, rocks, metals and film.

Structure and Features
Our ZST series drum screen machine is mainly composed of screen drum, vat, driving roller, inlet trough, and shower pipe. As the screen drum rotates, the stock is pushed forward. Then accepts and small impurities will enter the stock vat by the force of gravity, while the large impurities will be discharged along the track of the screw board. The fiber adhered to the impurities is washed off by water spraying device to keep fiber loss to a minimum.
The drum screen is often used together with hydrapulper to screen out coarse impurities, improving the purifying efficiency of process. Due to our consistent focus on product improvement, our drum screen machine is of simple structure, safe operation and high screening efficiency.

Specifications of Drum Screen Machine
Model Production amount (m3/h) Screen drum diameter(mm) Screen hole diameter(mm) Motor power(KW)
ZST0 30 Ф800 Ф8~Ф14 2.2
ZST31 60 Ф1000 4
ZST32 120 Ф1250 7.5
ZST33 240 Ф1500 11
ZST34 300 Ф2000 11
